Model No. GFG 318
Type Optical Flap Turnstile
Flexibility Integrate with any access control
Framework Material 304 Stainless steel+ Plexiglas glass arm+ tempered glass side panels with dazzling LED light
Arm material Plexiglas-transparency
Dimension 1200 *185 * 1000 mm
Net Weight 70kg/pcs (single core), 80kg/pcs (double core)
Passage Width 600 mm (standard), 900 mm(wheelchair)
Passing Direction Single directional / Bi-directional
MCBF 12 million
Power Supply AC220V/110V, 50/60Hz
Operation Voltage 24V DC
Power Consumption 40W
Operation Temperature -20 °C – 75 °C
Operation Humidity 0 ~ 95% (No freeze)
Working Environment Indoor / Outdoor (IP65)
Flow Rate 55-60 people per minute
LED Indicator Two LED indicators on top: green “→” entry. red “—” no entry
Infrared Sensor 5 pairs (3 pairs on the top +2 pairs on the below)
Emergency Automatic arm open when power off
